NGUỒN KÍN NƯỚC MEANWELL 24V 100W LPV-100-24

MODEL

LPV-100-5

LPV-100-12

LPV-100-15

LPV-100-24

LPV-100-36

LPV-100-48

OUTPUT

DC VOLTAGE

5V

12V

15V

24V

36V

48V

RATED CURRENT

12A

8.5A

6.7A

4.2A

2.8A

2.1A

CURRENT RANGE

0 ~ 12A

0 ~ 8.5A

0 ~ 6.7A

0 ~ 4.2A

0 ~ 2.8A

0 ~ 2.1A

RATED POWER

60W

102W

100.5W

100.8W

100.8W

100.8W

RIPPLE & NOISE (max.) Note.2

80mVp-p

120mVp-p

120mVp-p

150mVp-p

150mVp-p

150mVp-p

VOLTAGE TOLERANCE   Note.3

±8.0%

±5.0%

LINE REGULATION

±1.0%

LOAD REGULATION

±6.0%

±2.0%

SETUP, RISE TIME                                        Note.6

2000ms, 25ms / 230VAC    2000ms, 25ms / 115VAC

HOLD UP TIME (Typ.)

50ms/230VAC         14ms/115VAC at full load

INPUT

VOLTAGE RANGE                                        Note.4

90 ~ 264VAC         127 ~ 370VDC

FREQUENCY RANGE

47 ~ 63Hz

EFFICIENCY (Typ.)

80%

85%

87%

88%

88%

89%

AC CURRENT

2.2A/115VAC     1.2A/230VAC

INRUSH CURRENT(Typ.)

COLD START 75A(twidth=700μs measured at 50% Ipeak) at 230VAC

MAX. No. of PSUs on 16A CIRCUIT BREAKER

2 units (circuit breaker of type B) / 3 units (circuit breaker of type C) at 230VAC

LEAKAGE CURRENT

0.25mA / 240VAC

PROTECTION

OVERLOAD

110 ~ 150% rated output power

Protection type : Hiccup mode, recovers automatically after fault condition is removed

OVER VOLTAGE

5.75 ~ 6.75V

13.8 ~ 16.2V

17.25 ~ 20.25V

27.6 ~ 32.4V

41.4 ~ 48.6V

55.2 ~ 64.8V

Protection type : Shut down o/p voltage, re-power on to recover

ENVIRONMENT

WORKING TEMP.

-25 ~ +70℃ (Refer to "Derating Curve")

WORKING HUMIDITY

20 ~ 90% RH non-condensing

STORAGE TEMP., HUMIDITY

-40 ~ +80℃, 10 ~ 95% RH

TEMP. COEFFICIENT

±0.03%/℃ (0 ~ 50℃)

VIBRATION

10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes

SAFETY & EMC

SAFETY STANDARDS

UL8750,CSA C22.2 No 250.13-12,UL879,CSA C22.2 No.207-M89,BIS IS15885(Note12),

EAC TP TC 004,IP67, IEC62368-1 , BS EN/EN62368-1 approved

WITHSTAND VOLTAGE

I/P-O/P:3KVAC

ISOLATION RESISTANCE

I/P-O/P:>100M Ohms / 500VDC / 25℃/ 70% RH

EMC EMISSION

Compliance to BS EN/EN55032 (CISPR32) Class B, BS EN/EN61000-3-2  Class A(≤80% load), BS EN/EN61000-3-3, EAC TP TC 020

EMC IMMUNITY

Compliance to BS EN/EN61000-4-2,3,4,5,6,8,11; BS EN/EN55035, light industry level,  EAC TP TC 020

OTHERS

MTBF

4497.1K hrs min.

Telcordia SR-332 (Bellcore) ;

681.6Khrs min.

MIL-HDBK-217F (25℃)

DIMENSION

190*52*37mm (L*W*H)

PACKING

0.63Kg;20pcs/13.6Kg/0.55CUFT
